ORTHOGRAPHIC PROJECTIONS - ENGINEERING DRAWING

Model is an educational concept for beginners in technical drawing. A three dimensional stand which consists of six Perspex planes with associated views inserted on each plane of the stand enables a direct comparison between the work piece and the drawing.

The planes folds into a box making it easy to carry. It opens up flat to represent projections on sheet. Models are designed to clear fundamentals of visible, hidden and centre lines


Features:-

FIRST AND THIRD ANGLE

EASY TO CARRY BOX

LIGHT IN WEIGHT

VARIETY OF SHAPES
